Competitive High quality wheel loader L968F
Advantage introduction :
Reliable
1、The wheel loader is equipped with Weichai WD10G240E202 engine which features high power reserve, high torque, strong power, low fuel consumption, high quality, low emission and high reability.
2、VRT200 gearbox is adopted with front four and rear four gear positions to render better transmission efficiency and larger transmission ratio of forward positions 1 and 2 owing to the one additional position, and its comprehensive efficiency is increased by over 8%。
3 Reinforced drive axle is adopted with strengthened design, strict technology and guaranteed quality. The rear axle adopts the swing type support with improved reliability, large bearing capacity and service life increased by 50%.
4、The new generation of brand new optimized front and rear frames are adopted with reliable VOLVO technological reliability, rational distribution of load, rational structure and twofold fatigue life.
5、The working hydraulic system adopts high-end Parker multiway valves and Permco working pumps which are reliable and highly efficient.
6、Steel engine hood produced using automotive grade molds is adopted. It adopts the streamlined structure with surface welded points removed, making it look attractive and magnificent. The molded balance iron employs a more powerful shape to provide high reliability and strength.
Energy efficient
The electric control high pressure common rail engine is adopted with torque increased by 12% to provide better power performance.
Comfortable
1、Compared to the mechanical engine, the electric control engine is characterized by low noise and small vibration, thus increasing the comfort during operation and driving.
2、The new generation cab is adopted with space increased by 15% to enhance safety and comfort. The attractive curved front windshield provides a broad view.
Convenient
1、The engine hood and heat dissipation hood adopt the large opening design to provide larger space for maintenance.
2、The oil cylinder adopts a unified design and the seals have a universal height to facilitate storage of accessories and maintenance.
3、Electric system centralized control mode is adopted. The fuse and relay of the entire machine are installed in a centralized control box to facilitate inspection and maintenance.
L*W*H | 8680*3200*3470mm |
Wheel base | 3400mm |
Min. ground clearance | 530mm |
Max. dumping height | 3250mm |
Dumping distance | 1090mm |
Dumping angle | 45 |
wheel tread | 2250mm |
steering angle | 38 |
horizontal crossing radius | 7140mm |
Min. turning radius | 6062mm |
Overall parameters |
|
Backet capacity | 3.5m3(optional 3.0-5.0) |
Rated load | 6000kg |
operating weight | 19950kg |
Max. tractive force | 180kN |
Max. breakout force | 210kN |
Tipping load | 128kN |
Engine |
|
Model | WD10G240E201 |
Type | Inline, watercooled, dry cylinder liner, direct injection |
Rated power | 178kW |
Rated speed | 2200r/min |
Engine displacement | 9726ml |
Max. torque | 1000N.m |
Emission standard | GB 20891-2007(China Phase II) |
Min. fuel-consume ratio | 230g/kw.h |
Transmission system |
|
Torgue converter | single-stage three-element single-turbine hydraulic torque converter |
Transmission type | Axis-fixed electro-hydraulic transmission |
Gears | Forward 4 reverse 4 |
Hydraulic system of working device |
|
Type | Hydraulic pilot control |
total time | 10.3s |
Brake system |
|
Service brake type | Air over hydraulic disc type |
Parking brake type | Electric pneumatic caliper disc type |
Steering system |
|
Type | Load sensing full hydraulic articulated steering |
System pressure | 21 Mpa |
Fill capacity |
|
Fuel | 350L |
Hydraulic oil | 220L |
Engine | 20L |
Transmission | 28.4L |
Drive axle | Forward 40L+ reverse 40L |
Braking system | 4L |
